Park Air Profiles - Great Sand Dunes National Park & Preserve

Air Quality at Great Sand Dunes National Park & Preserve

Most visitors expect clean air and clear views in parks. Great Sand Dunes National Park & Preserve (NP & Pres), Colorado, home to the tallest dunes in North America, is downwind of many pollution sources. Air pollutants blown into the park can harm natural and scenic resources such as soils, surface waters, plants, wildlife, and visibility. The National Park Service works to address air pollution effects at Great Sand Dunes NP & Pres, and in parks across the U.S., through science, policy and planning, and by doing our part.

Nitrogen and Sulfur

Visitors come to Great Sand Dunes NP & Pres to enjoy scenic views of the Rocky Mountains and the tallest sand dunes in North America.

Nitrogen (N) and sulfur (S) compounds deposited from the air may have harmful effects on ecosystem processes. Healthy ecosystems can naturally buffer a certain amount of pollution, but once a threshold is passed the ecosystem may respond negatively. This threshold is the critical load, or the amount of pollution above which harmful changes in sensitive ecosystems occur (Porter 2005). N and S deposition change ecosystems through eutrophication (N deposition) and acidification (N + S deposition). Eutrophication increases soil and water nutrients which causes some species to grow more quickly and changes community composition. Ecosystem sensitivity to nutrient N enrichment at Great Sand Dunes National Park and Preserve (GRSA) relative to other national parks is very high (Sullivan et al. 2016); for a full list of N sensitive ecosystem components, see: NPS ARD 2019. Acidification leaches important cations from soils, lakes, ponds, and streams which decreases habitat quality. Ecosystem sensitivity to acidification at GRSA relative to other national parks is very high (Sullivan et al. 2016); to search for acid-sensitive plant species, see: NPSpecies.

From 2017-2019 total N deposition in GRSA ranged from 3.0 to 4.9 kg-N ha^-1 yr^-1 and total S deposition ranged from 0.7 to 1.3 kg-S ha^-1 yr^-1 based on the TDep model (NADP, 2018). GRSA has been monitoring atmospheric N and S deposition since 1980, see the conditions and trends website for park-specific information.

Alpine ecosystem effects

Alpine environments are particularly vulnerable to large inputs of reactive nitrogen because of the sparse cover of vegetation, short growing seasons, large areas of exposed bedrock and talus, and snowmelt nutrient releases (Williams et al., 1996; Nanus et al., 2012). Approximately 5% of the land area in GRSA is alpine (~328 km² above 1550 m). McClung et al. (2020) compared the 2015 estimated total N deposition (TDep; NADP, 2018) to the critical load of N for an increase in alpine sedge growth (alpine plant critical load = 3 kg-N ha^-1yr^-1) and the critical load of N for alpine soil nitrate leaching (alpine soil critical load = 10 kg-N ha^-1yr^-1; Bowman et al., 2012). They found that deposition exceeded the alpine plant critical load 100% of the park’s alpine area, but was below the alpine soil critical load throughout the park’s entire alpine area.

Epiphytic macrolichen community responses

Epiphytic macrolichens grow on tree trunks, branches, and boles. Since these lichens grow above the ground, they obtain all their nutrients directly from precipitation and the air. Many epiphytic lichen species have narrow environmental niches and are extremely sensitive to changes in air pollution. Geiser et al. (2019) used a U.S. Forest Service national survey to develop critical loads of nitrogen (N) and critical loads of sulfur (S) to prevent more than a 20% decline in four lichen community metrics: total species richness, pollution sensitive species richness, forage lichen abundance, and cyanolichen abundance.

McCoy et al. (2021) used forested area from the National Land Cover Database to estimate the impact of air pollution on epiphytic lichen communities. Forested area makes up 113 km² (18.9%) of the land area of Great Sand Dunes National Park and Preserve.

• N deposition exceeded the 3.1 kg-N ha^-1 yr^-1 critical load to protect N-sensitive lichen species richness in 83.8% of the forested area.
• S deposition was below the 2.7 kg-S ha^-1 yr^-1 critical load to protect S-sensitive lichen species richness in every part of the forested area.

For exceedances of other lichen metrics and the predicted decline of lichen communities see Appendices A and B of McCoy et al. (2021).

Additional modeling was done on 459 lichen species to test the combined effects of air pollution and climate gradients (Geiser et al. 2021). A critical load indicative of initial shifts from pollution-sensitive toward pollution-tolerant species occurred at 1.5 kg-N ha^-1 yr^-1 and 2.7 kg-S ha^-1 yr^-1 even under changing climate regimes.

Plant species response

Plants vary in their tolerance of eutrophication and acidification, and some plant species respond to nitrogen (N) or sulfur (S) pollution with declines in growth, survival, or abundance on the landscape. Horn et al. (2018) used the U.S. Forest Service national forest survey to develop critical loads of N and critical loads of S to prevent declines in growth or survival of sensitive tree species. Clark et al. (2019) used a database of plant community surveys to develop critical loads of N and critical loads of S to prevent a decline in abundance of sensitive herbaceous plant species. According to NPSpecies, Great Sand Dunes National Park and Preserve contains:

• 3 N-sensitive tree species and 23 N-sensitive herbaceous species.
• 6 S-sensitive tree species and 20 S-sensitive herbaceous species.

Mycorrhizal fungi community response

Many plants have a symbiotic relationship with mycorrhizal fungi (MF). Through the roots, the plants supply the fungi with carbon from photosynthesis and in exchange the MF enhance nutrient availability within soils, increase drought tolerance, and provide physical resistance to soil erosion (George et al., 1995; Cheng et al., 2021; Burri et al., 2013). Anthropogenic Nitrogen (N) deposition can disrupt this symbiotic relationship resulting in a shift from N sensitive to N tolerant mycorrhizal fungi and plant communities.

With increased N deposition to the soil, MF become less important for nutrient uptake and many plants will cease the exchange of nutrients altogether making them more vulnerable to stressors such as drought (Lilleskov et al., 2019). The CL-N for the shift in mycorrhizal community is 5-6 kg-N ha^-1 yr^-1 in coniferous forests and 10-20 kg-N ha^-1 yr^-1 broadleaf forests.

Great Sand Dunes National Park has 126.2 km² of coniferous forests, 26 km² of broadleaf forests, and 4.9 km² of mixed forests. Using the range in critical loads above, the minimum CL is exceeded in 0% of forested area and the maximum CL is exceeded in 0% of forested area based on 2019-2021 TDep Total N deposition.

Change in N and S deposition from 2000 to 2021

The maps below show how the spatial distribution of estimated Total N and Total S deposition in GRSA has changed from 2000-2002 to 2019-2021 (TDep MMF version 2022.02). Slide the arrows in the middle of the image up and down to compare N and S deposition between the two years (Yearly Data).

• Minimum N deposition remained at 1.5 kg-N ha^-1 yr^-1 and maximum N deposition increased from 5.4 to 5.7 kg-N ha^-1 yr^-1.
• Minimum S deposition decreased from 0.5 to 0.3 kg-S ha^-1 yr^-1 and maximum S deposition decreased from 2.0 to 1.4 kg-S ha^-1 yr^-1.

Estimated total nitrogen and sulfur deposition levels from 2000-2002 (top) compared to the 2019-2021 (bottom) average at GRSA. Estimated values were developed using the National Atmospheric Deposition Program - Total Deposition (TDep) approach that combines measured and modeled data. Estimated values are valuable for analyzing gradients of deposition and the resulting ecosystem risks where monitors are not present.

Persistent Pollutants

Pollutants like mercury and pesticides are concerning because they are persistent and toxic in the environment. These contaminants can travel in the air thousands of miles away from the source of pollution, even depositing in protected places like national parks. In addition, while some of these harmful pollutants may be banned from use, historically contaminated sites continue to endure negative environmental consequences.

When deposited, airborne mercury and other toxic air contaminants are known to harm wildlife like birds and fish, and cause human health concerns. Many of these substances enter the food chain and accumulate in the tissue of organisms causing reduced reproductive success, impaired growth and development, and decreased survival.

• Mercury concentrations in fish sampled at Great Sand Dunes NP & Preserve did not exceed any thresholds for fish toxicity, bird toxicity, or US EPA’s human consumption guidance. Fish were analyzed for mercury from two sites at the park and compared to data across 21 western parks. The average fish mercury concentration (52.7 ng/g ww) was slightly lower than the study-wide mean (77.7 ng/g ww) (Eagles-Smith et al. 2014). However, the data may not reflect the risk at other unsampled locations in the park.
• No fish sampled from the park were found to be intersex (Schreck and Kent 2013). Reproductive abnormalities such as intersex, the presence of both male and female reproductive structures in the same fish, can signify exposure to contaminants. Fish consumption advisories may be in effect for mercury and other contaminants (NPS 2022).
• Some dragonfly larvae sampled at Great Sand Dunes NP & Preserve had mercury concentrations at moderate or higher impairment levels. Dragonfly larvae have been sampled and analyzed for mercury from three sites in the park; 31% of the data fall into the moderate (100-300 ng/g dw) and 31% fall into the high (>300 ng/g dw) impairment categories for potential mercury risk. An index of moderate impairment or higher suggests some fish may exceed the US EPA benchmark for protection of human health (Eagles-Smith et al. 2021; Eagles-Smith et al. 2020).
• Pesticides were found in park fish and water. Dieldrin (a historic-use pesticide) concentrations in 50% of cutthroat trout sampled from Sand Creek exceeded the subsistence consumption threshold established for human health. Concentrations of current-use pesticides in fish are particularly high for parks in the Rockies and Sierra Nevada, as compared to parks in Alaska and the Cascades (Flanagan Pritz et al. 2014). Pesticide concentrations in water samples from Sand Creek and Medano Creek did not exceed any known benchmarks for aquatic life (Keteles 2011).
• Airborne contaminants were found in park air and vegetation samples. SOC (semi-volatile organic compound) concentrations found in Great Sand Dunes NP vegetation were generally higher than concentrations in other western parks (Landers et al. 2010; Landers et al. 2008). The dominant SOCs found in vegetation included PAHs (polycyclic aromatic hydrocarbons) and DDTs. SOC concentrations detected in air were moderate-to-high compared to other western parks.
• Mercury was found in park snow samples. In 2021, the average mercury concentration found in snowpack at Music Pass was 6.72 ng/L (Ingersoll et al. 2007; USGS 2021).

The NPS Air Resources Division reports on park conditions and trends for mercury. Visit the webpage to learn more.

Visibility

Clean, clear air is essential to appreciating the scenic vistas at Great Sand Dunes NP & Pres.

Visitors come to Great Sand Dunes NP & Pres to enjoy views of impressive sand dunes against the backdrop of the Sangre de Cristo mountain range. Park vistas are sometimes obscured by haze, reducing how well and how far people can see. Visibility reducing haze is caused by tiny particles in the air, and these particles can also affect human health. Many of the same pollutants that ultimately fall out as nitrogen and sulfur deposition contribute to this haze. Organic compounds, soot, and dust reduce visibility as well. Significant improvements in park visibility on clearest days have been documented since the 1990’s. However, no significant trends have occurred on haziest days and visibility in the park still needs improvement to reach the Clean Air Act goal of no human caused impairment.

Visibility effects:

• Reduction of the average natural visual range from about 170 miles (without the effects of pollution) to about 125 miles because of pollution at the park
• Reduction of the visual range to below 85 miles on high pollution days

Visit the NPS air quality conditions and trends website for park-specific visibility information. Great Sand Dunes NP & Pres has been monitoring visibility since 1988. Explore air monitoring »

Ground-Level Ozone

Quaking Aspen trees are one of the ozone sensitive species found at Great Sand Dunes NP & Pres.

At ground level, ozone is harmful to human health and the environment. Ground-level ozone does not come directly from smokestacks or vehicles, but instead is formed when other pollutants, mainly nitrogen oxides and volatile organic compounds, react in the presence of sunlight.

Over the course of a growing season, ozone can damage plant tissues making it harder for plants to grow and store carbon. The US Environmental Protection Agency led ozone exposure experiments on trees that are abundant in United States forests. Experimental results showed ozone slowed tree seedling growth. NPS uses W126 values of 7 and 13 ppm-h from averaged tree response in those experiments to describe Vegetation Health condition in parks. A recent re-analysis of those experiments established critical levels of ozone protective of each tree species tested, rather than to tree seedlings as a class of vegetation (Lee et al. 2022).

The ozone critical levels are W126 values that will prevent 5% or greater loss of tree seedling biomass. Some tree species are ozone sensitive and have critical levels lower than the current ARD breakpoints of 7 and 13 ppm-h. Some tree species are ozone tolerant, and their critical levels are higher than the current breakpoints. ARD Conditions and Trends reports a 5-year average of W126 for each park. In 2018-2022, the average W126 value for Great Sand Dunes National Park and Preserve was 16.1 ppm-h. Based on this [FQE1] ozone level, trees present in the park (NPSpecies) are at risk of the following ozone effects:

• The tree species Ponderosa Pine (Pinus Ponderosa, var. scopulorum), with an ozone critical level of 6 ppm-h, is at risk of 11% biomass loss in seedlings. The tree species Quaking Aspen (Populus Tremuloides), with an ozone critical level of 9 ppm-h, is at risk of 11% biomass loss in seedlings. Recent ozone levels in the park exceed critical levels that protect these species
• Tree species Douglas-Fir (Pseudotsuga Menziesii, critical level of 51.4) is at low risk of ozone effects. Recent ozone levels in the park are below critical levels that protect these from 5% or greater biomass loss.

Ozone critical levels are for tree seedlings, which represent the regenerative capacity and long-term stability of sensitive species within a forest. These tree species are also known to be sensitive to ozone as adults (Bell et al 2020), but critical values for seedling growth do not predict ozone effects on adult trees. ARD is currently working with collaborators to establish critical levels for adult trees using data from forest monitoring plots.

Visit the NPS air quality conditions and trends website for park-specific ozone information.

Explore Other Park Air Profiles

There are 47 other Park Air Profiles covering parks across the United States and its territories.

References

Bell MD, Felker-Quinn E, Kohut R. 2020. Ozone sensitive plant species on National Park Service lands. Natural Resource Report. NPS/WASO/NRR—2020/2062. National Park Service. Fort Collins, Colorado. https://irma.nps.gov/DataStore/Reference/Profile/2271702

Bowman W, Murgel J, Blett T, Porter E. 2012. Nitrogen critical loads for alpine vegetation and soils in Rocky Mountain National Park. Journal of Environmental Management. 103:165-171

Bowman WD, Gartner JR, Holland K, Wiedermann M. Nitrogen critical loads for alpine vegetation and terrestrial ecosystem response: are we there yet? Ecol Appl. 2006 Jun;16(3):1183-93. doi: 10.1890/1051-0761(2006)016[1183:nclfav]2.0.co;2. PMID: 16827011.

Burri, K., C. Gromke, and F. Graf. "Mycorrhizal fungi protect the soil from wind erosion: a wind tunnel study." Land Degradation & Development 24.4 (2013): 385-392.

Cheng, Shen, et al. "Elucidating the mechanisms underlying enhanced drought tolerance in plants mediated by arbuscular mycorrhizal fungi." Frontiers in Microbiology 12 (2021): 809473.

Clark, C.M., Simkin, S.M., Allen, E.B. et al. Potential vulnerability of 348 herbaceous species to atmospheric deposition of nitrogen and sulfur in the United States. Nat. Plants 5, 697–705 (2019). https://doi.org/10.1038/s41477-019-0442-8

Eagles-Smith, C.A., J.J. Willacker, and C.M.Flanagan Pritz. 2014. Mercury in fishes from 21 national parks in the Western United States—Inter and intra-park variation in concentrations and ecological risk: U.S. Geological Survey Open-File Report 2014-1051, 54 p. Available at: http://dx.doi.org/10.3133/ofr20141051

Eagles-Smith, C.A., J.J. Willacker, S.J. Nelson, C.M. Flanagan Pritz, D.P. Krabbenhoft, C.Y. Chen, J.T. Ackerman, E.H. Campbell Grant, and D.S. Pilliod. 2020. Dragonflies as biosentinels of mercury availability in aquatic food webs of national parks throughout the United States. Environmental Science and Technology 54(14):8779-8790. https://doi.org/10.1021/acs.est.0c01255

Eagles-Smith, C.A., S.J. Nelson., C.M. Flanagan Pritz, J.J. Willacker Jr., and A. Klemmer. 2018. Total Mercury Concentrations in Dragonfly Larvae from U.S. National Parks (ver. 6.0, June 2021): U.S. Geological Survey data release. https://doi.org/10.5066/P9TK6NPT

Felker-Quinn E, Devore L, Clemens C. 2022. Investigator Annual Report on Conducting scouting surveys for ozone sensitive plants at Great Sand Dunes National Park & Preserve. National Park Service Research Permit and Reporting System. https://irma.nps.gov/RPRS/IAR/Profile/572768

Flanagan Pritz, C. M., J. E. Schrlau, S. L. Massey Simonich, T. F. Blett. 2014. Contaminants of Emerging Concern in Fish from Western U.S. and Alaskan National Parks – Spatial Distribution and Health Thresholds. Journal of American Water Resources Association 50 (2): 309–323. Available at https://irma.nps.gov/App/Reference/Profile/2210538.

Geiser, Linda & Nelson, Peter & Jovan, Sarah & Root, Heather & Clark, Christopher. (2019). Assessing Ecological Risks from Atmospheric Deposition of Nitrogen and Sulfur to US Forests Using Epiphytic Macrolichens. Diversity. 11. 87. 10.3390/d11060087.

Geiser, Linda & Root, Heather & Smith, Robert & Jovan, Sarah & Clair, Larry & Dillman, Karen. (2021). Lichen-based critical loads for deposition of nitrogen and sulfur in US forests. Environmental Pollution. 291. 118187. 10.1016/j.envpol.2021.118187.

George, Eckhard, Horst Marschner, and Iver Jakobsen. "Role of arbuscular mycorrhizal fungi in uptake of phosphorus and nitrogen from soil." Critical reviews in biotechnology 15.3-4 (1995): 257-270.

Horn KJ, Thomas RQ, Clark CM, Pardo LH, Fenn ME, Lawrence GB, et al. (2018) Growth and survival relationships of 71 tree species with nitrogen and sulfur deposition across the conterminous U.S.. PLoS ONE 13(10): e0205296. https://doi.org/10.1371/journal.pone.0205296

Ingersoll, G. P., Mast, M. A., Nanus, L., Handran, H. H., Manthorne, D. J., and Hultstrand, D. M. 2007. Rocky Mountain snowpack chemistry at selected sites, 2004: U.S. Geological Survey Open-File Report 2007-1045, 15 p. Available at https://pubs.usgs.gov/of/2007/1045/

Keteles, K. 2011. Screening for Pesticides in High Elevation Lakes in Federal Lands. EPA Final Report. Denver, CO. 11 pp. Available at https://irma.nps.gov/DataStore/Reference/Profile/2184330

Kohut, R., Flanagan, C., Cheatham, J., Porter, E. 2012. Foliar Ozone Injury on Cutleaf Coneflower at Rocky Mountain National Park, Colorado, U.S.A. Western North American Naturalist 72(1), 32-42. https://doi.org/10.3398/064.072.0104

Landers, D. H., S. L. Simonich, D. A. Jaffe, L. H. Geiser, D. H. Campbell, A. R. Schwindt, C. B. Schreck, M. L. Kent, W. D. Hafner, H. E. Taylor, K. J. Hageman, S. Usenko, L. K. Ackerman, J. E. Schrlau, N. L. Rose, T. F. Blett, and M. M. Erway. 2008. The Fate, Transport, and Ecological Impacts of Airborne Contaminants in Western National Parks (USA). EPA/600/R—07/138. U.S. Environmental Protection Agency, Office of Research and Development, NHEERL, Western Ecology Division, Corvallis, Oregon. Available at https://irma.nps.gov/DataStore/Reference/Profile/660829.

Landers, D. H., Simonich, S. M., Jaffe, D., Geiser, L., Campbell, D. H., Schwindt, A., Schreck, C., Kent, M., Hafner, W., Taylor, H. E., Hageman, K., Usenko, S., Ackerman, L., Schrlau, J., Rose, N., Blett, T., Erway, M. M. 2010. The Western Airborne Contaminant Assessment Project (WACAP): An Interdisciplinary Evaluation of the Impacts of Airborne Contaminants in Western U.S. National Parks. Environmental Science and Technology 44: 855–859. Available at https://pubs.acs.org/doi/10.1021/es901866e

Lee EH, Anderson CP, Beedlow PA, Tingey DT, Koike S, Dubois J, Kaylor SD, Novak K, Rice RB, Neufeld HS, Herrick JD. 2022. Ozone Exposure-Response Relationships Parametrized for Sixteen Tree Species with Varying Sensitivity in the United States. Atmospheric Environment. 284:1-16. https://irma.nps.gov/DataStore/Reference/Profile/2294221

Lilleskov, Erik A., et al. "Atmospheric nitrogen deposition impacts on the structure and function of forest mycorrhizal communities: a review." Environmental Pollution 246 (2019): 148-162.

McClung JJ, Bell MD, Felker-Quinn E. 2021. Extrapolating critical loads of nitrogen for alpine vegetation and assessing exceedance in national parks based on TDep Total N from 2002–2016. Natural Resource Report. NPS/NRSS/ARD/NRR—2021/2240. National Park Service. Fort Collins, Colorado. https://doi.org/10.36967/nrr-2284914

McCoy K., M. D. Bell, and E. Felker-Quinn. 2021. Risk to epiphytic lichen communities in NPS units from atmospheric nitrogen and sulfur pollution: Changes in critical load exceedances from 2001‒2016. Natural Resource Report NPS/NRSS/ARD/NRR—2021/2299. National Park Service, Fort Collins, Colorado. https://doi.org/10.36967/nrr-2287254.

[NADP] National Atmospheric Deposition Program. 2018. NTN Data. Accessed January 20, 2022. Available at http://nadp.slh.wisc.edu/NADP/

Nanus L, Clow D, Saros J, Stephens V, Campbell D. 2012. Mapping Critical Loads of Nitrogen Deposition for Aquatic Ecosystems in the Rocky Mountains, USA.. Environmental Pollution. 166:125-135

Nanus, L., Williams, M. W., Campbell, D. H., Tonnessen, K. A., Blett, T., and Clow, D. W. 2009. Assessment of lake sensitivity to acidic deposition in national parks of the Rocky Mountains. Ecological Applications 19(4): 961–973.

[NPS] National Park Service. 2022. Fish Consumption Advisories. https://www.nps.gov/subjects/fishing/fish-consumption-advisories.htm

Porter, E. and Johnson, S. 2007. Translating science into policy: Using ecosystem thresholds to protect resources in Rocky Mountain National Park. Environmental Pollution 149: 268–280.

Porter, E., Blett, T., Potter, D.U., Huber, C. 2005. Protecting resources on federal lands: Implications of critical loads for atmospheric deposition of nitrogen and sulfur. BioScience 55(7): 603–612. https://doi.org/10.1641/0006-3568(2005)055[0603:PROFLI]2.0.CO;2

Schreck, C.B. and M. Kent. 2013. Extent of Endocrine Disruption in Fish of Western and Alaskan National Parks. NPS-OSU Task Agreement J8W07080024. NPS Final Report, 72 pp. https://irma.nps.gov/DataStore/DownloadFile/469831

Sullivan, T. J. 2016. Air quality related values (AQRVs) in national parks: Effects from ozone; visibility reducing particles; and atmospheric deposition of acids, nutrients and toxics. Natural Resource Report NPS/NRSS/ARD/NRR—2016/1196. National Park Service, Fort Collins, CO.

U.S. Geological Survey (USGS). 2021. Rocky Mountain Regional Snowpack Chemistry Monitoring Study. USGS data available at https://www.usgs.gov/centers/colorado-water-science-center/science/rocky-mountain-regional-snowpack-chemistry-monitoring#overview

Williams MW, Baron JS, Caine N, Sommerfeld R, Sanford R. 1996. Nitrogen saturation in the Rocky Mountains. Environmental Science & Technology. 30(2):640-646
